VICTRON Quattro - 48V 15000VA/200A
The Quattro is not just an inverter.
It is a power management system.
Key Functions
1. Zero-Interruption Switching
Transfers from grid to battery in under 20 milliseconds — machines keep running.
2. PowerAssist Technology
Supports heavy startup loads like compressors and motors.
3. Dual AC Inputs
Can connect grid + generator simultaneously.
4. Parallel Operation
Scales to large industrial
.
AC input voltage: 187-265 VAC 45-65 Hz
Output voltage: 230 V (± 2%) - 50 Hz (± 0.1%)
Voltage waveform: Pure sine wave
Nominal battery voltage: 48 V
Recommended battery capacity: 200–1600Ah
Recommended DC fuse: 300A
Recommended battery cabling: 2 x 50 mm2 (for a distance of 5 to 10 meters to the battery: 2 x 95 mm2)
Continuous power at 25 °C: 15,000 VA (15000 W)
Continuous power at 40 °C: 12000 W
Peak power: 32,000 W
AC connection: M6 bolts
Battery connection: 4 times M8 bolts
Efficiency: 96 %
Display/read-out: LED display
Inverter input voltage: 38 – 66V
PowerControl/PowerAssist: Yes
Charging current house battery/accessory battery: 110A
Charging current starter battery: N/A
Ambient temperature: -40 °C to 65 °C
Cooling: Fan cooling
Protections: Overtemperature, overload, short circuit, high/low battery voltage
